WT-650 | WT-850 | |||
---|---|---|---|---|
Max. Width of film for Unwinder (mm) | 1300 | 1600 | ||
Bag Length 'Sealing Width' (mm) | 200-650 | 200-850 | ||
Bag Width 'Draw Length' (mm) | 150-420 | 150-420 | ||
Max. Production Speed (pieces/ min) | 330 | 330 | ||
Thickness of the Film (mm) | 0,018-0,070 | 0,018-0,070 | ||
HDPE | 0,018 -0,030 | 0,018 -0,030 | ||
LDPE | 0,025- 0,070 | 0,025- 0,070 | ||
PP | 0,020-0,050 | 0,020-0,050 | ||
Total Air Consumption (litre/ min) | 500 | 500 | ||
Total Installed Power (kW) | 30 | 33 | ||
Machine Sizes(m) | ||||
Length | 9,5 | 10,1 | ||
Width | 1,9 | 2,1 | ||
Height | 2,4 | 2,7 |
